Binary Protected Attributes

Introduction

We illustrate the usage of the fairmetrics package through a case study using a publicly available dataset of 1,776 ICU patients from the MIMIC-II clinical database, focusing on predicting 28-day mortality and evaluating disparities in model performance across sex.

The following packages are used for the analysis along with the fairmetrics package:

# Packages we are using for the analysis
library(dplyr)
library(corrplot)
library(randomForest)
library(pROC)
library(SpecsVerification)
library(kableExtra)
library(naniar)
# Our package
library(fairmetrics)

The “Data Preprocessing” section discusses the dataset, the handling of missing data, model construction and standard predictive model evaluation through train-test splitting for binary classification. The “Fairness Evaluation” section shows how to evaluate the model’s fairness toward binary protected attributes with the fairmetrics package.

Data Preprocessing

The dataset used in this analysis is the MIMIC II clinical database [2], which has been previously studied to explore the relationship between indwelling arterial catheters in hemodynamically stable patients and respiratory failure in relation to mortality outcomes [3]. It includes 46 variables which cover demographics and clinical characteristics (including white blood cell count, heart rate during ICU stays and others) along with a 28-day mortality indicator (day_28_flg) for 1,776 patients. The data has been made publicly available by PhysioNet [4] and is available in the fairmetrics package as the mimic dataset.

Handling Missing Data

We first assess the extent of missingness in the dataset. For each variable, we calculate both the total number and the percentage of missing values with naniar::miss_var_summary().

# Loading mimic dataset
# (available in fairmetrics)
data("mimic")

missing_data_summary<- naniar::miss_var_summary(mimic, digits= 3)

kableExtra::kable(missing_data_summary, booktabs = TRUE, escape = FALSE) %>%
  kableExtra::kable_styling(
    latex_options = "hold_position"
  )

variable	n_miss	pct_miss
bmi	466	26.239
po2_first	186	10.473
pco2_first	186	10.473
iv_day_1	143	8.052
weight_first	110	6.194
sapsi_first	85	4.786
wbc_first	8	0.450
hgb_first	8	0.450
platelet_first	8	0.450
sofa_first	6	0.338
creatinine_first	6	0.338
sodium_first	5	0.282
potassium_first	5	0.282
tco2_first	5	0.282
chloride_first	5	0.282
bun_first	5	0.282
temp_1st	3	0.169
gender_num	1	0.056
aline_flg	0	0.000
icu_los_day	0	0.000
hospital_los_day	0	0.000
age	0	0.000
service_unit	0	0.000
service_num	0	0.000
day_icu_intime	0	0.000
day_icu_intime_num	0	0.000
hour_icu_intime	0	0.000
hosp_exp_flg	0	0.000
icu_exp_flg	0	0.000
day_28_flg	0	0.000
mort_day_censored	0	0.000
censor_flg	0	0.000
sepsis_flg	0	0.000
chf_flg	0	0.000
afib_flg	0	0.000
renal_flg	0	0.000
liver_flg	0	0.000
copd_flg	0	0.000
cad_flg	0	0.000
stroke_flg	0	0.000
mal_flg	0	0.000
resp_flg	0	0.000
map_1st	0	0.000
hr_1st	0	0.000
spo2_1st	0	0.000
abg_count	0	0.000

To ensure data quality, the following procedure is applied to handle missing data:

• Removal of that variables which had more than 10% missing values. Three variables had more than 10% of missing values: body mass index (bmi; 26.2%), first partial pressure of oxygen (po2_first; 10.5%), and first partial pressure of carbon dioxide (pco2_first; 10.5%).

• Remaining missing values are imputed using the median value of the variable which they belong to.

# Remove columns with more than 10% missing values
columns_to_remove <- missing_data_summary %>%
  dplyr::filter(pct_miss > 10) %>%
  dplyr::pull(variable)

mimic <- dplyr::select(mimic,
                       -dplyr::one_of(columns_to_remove)
                       )

# Impute remaining missing values with median
mimic <- mimic %>%
  dplyr::mutate(
    dplyr::across(
      dplyr::where(~any(is.na(.))),
                  ~ifelse(is.na(.), median(., na.rm = TRUE), .)
                  )
    )

We additionally remove sepsis_flg column from the dataset as it contains a single unique value across all observations. Since this does not provide any useful information for model training, it is excluded.

# Identify columns that have only one unique value
cols_with_one_value <- sapply(mimic, function(x) length(unique(x)) == 1)
# Subset the dataframe to remove these columns
mimic <- mimic[, !cols_with_one_value]

Model Building

Before training the model, we further remove variables that are directly correlated with patient outcomes to prevent data leakage. In particular, we inspect the correlation matrix of the numeric features and exclude variables such as the hospital expiration flag (hosp_exp_flg), the ICU expiration flag (icu_exp_flg), the mortality censoring day (mort_day_censored), and the censoring flag (censor_flg), which are strongly associated patient outcomes.

# Remove columns that are highly correlated with the outcome variable
corrplot::corrplot(cor(select_if(mimic, is.numeric)), method = "color", tl.cex = 0.5)

mimic <- mimic %>%
  dplyr::select(-c("hosp_exp_flg", "icu_exp_flg", "mort_day_censored", "censor_flg"))

We split the dataset into a training and testing sets. The first 700 patients are used as the training set and the remaining patients are used as the testing set. The hyperparameters for the random forest (RF) model are set to use 1000 trees and a random sampling of 6 variables at each split, determined by the square root of the number of predictors. After training, the overall area under the receiver operating characteristic curve (AUC) for the model on the test set is 0.90 and the overall accuracy of the model on the test set is 0.88.

# Use 700 labels to train the mimic
train_data <- mimic %>%
  dplyr::filter(
    dplyr::row_number() <= 700
    )

# Fit a random forest model
set.seed(123)
rf_model <- randomForest::randomForest(factor(day_28_flg) ~ ., data = train_data, ntree = 1000)

# Test the model on the remaining data
test_data <- mimic %>%
  dplyr::filter(
    dplyr::row_number() > 700
    )

test_data$pred <- predict(rf_model, newdata = test_data, type = "prob")[,2]

# Check the AUC
roc_obj <- pROC::roc(test_data$day_28_flg, test_data$pred)
#> Setting levels: control = 0, case = 1
#> Setting direction: controls < cases
roc_auc <- pROC::auc(roc_obj)
roc_auc
#> Area under the curve: 0.8971

Fairness Evaluation

To evaluate fairness, we use the testing set results to examine patient gender as a binary protected attribute and 28-day mortality (day_28_flg) as the outcome of interest.

# Recode gender variable explicitly for readability:

test_data <- test_data %>%
  dplyr::mutate(gender = ifelse(gender_num == 1, "Male", "Female"))

Since many fairness metrics require binary predictions, we threshold the predicted probabilities using a fixed cutoff. We set a threshold of 0.41 to maintain the overall false positive rate (FPR) at approximately 5%.

# Control the overall false positive rate (FPR) at 5% by setting a threshold.

cut_off <- 0.41

test_data %>%
  dplyr::mutate(pred = ifelse(pred > cut_off, 1, 0)) %>%
  dplyr::filter(day_28_flg == 0) %>%
  dplyr::summarise(fpr = mean(pred))
#>          fpr
#> 1 0.05054945

To calculate various fairness metrics for the model, we pass our test data with its predicted results into the get_fairness_metrics function.

fairness_result <- fairmetrics::get_fairness_metrics(
  data = test_data,
  outcome = "day_28_flg",
  group = "gender",
  group2 = "age",
  condition = ">=60",
  probs = "pred",
  cutoff = cut_off
 )

kableExtra::kable(fairness_result, booktabs = TRUE, escape = FALSE) %>%
  kableExtra::kable_styling(full_width = FALSE) %>%
  kableExtra::pack_rows("Independence-based criteria", 1, 2) %>%
  kableExtra::pack_rows("Separation-based criteria", 3, 6) %>%
  kableExtra::pack_rows("Sufficiency-based criteria", 7, 7) %>%
  kableExtra::pack_rows("Other criteria", 8, 10) %>%
  kableExtra::kable_styling(
    full_width = FALSE,
    font_size = 10,         # Controls font size manually
    latex_options = "hold_position"
  )

Metric	GroupFemale	GroupMale	Difference	95% Diff CI	Ratio	95% Ratio CI
Independence-based criteria
Statistical Parity	0.17	0.08	0.09	[0.05, 0.13]	2.12	[1.48, 3.05]
Conditional Statistical Parity (age >=60)	0.34	0.21	0.13	[0.05, 0.21]	1.62	[1.18, 2.22]
Separation-based criteria
Equal Opportunity	0.38	0.62	-0.24	[-0.39, -0.09]	0.61	[0.44, 0.86]
Predictive Equality	0.08	0.03	0.05	[0.02, 0.08]	2.67	[1.39, 5.1]
Balance for Positive Class	0.46	0.37	0.09	[0.04, 0.14]	1.24	[1.09, 1.41]
Balance for Negative Class	0.15	0.10	0.05	[0.03, 0.07]	1.50	[1.29, 1.74]
Sufficiency-based criteria
Predictive Parity	0.62	0.66	-0.04	[-0.21, 0.13]	0.94	[0.72, 1.23]
Other criteria
Brier Score Parity	0.09	0.08	0.01	[-0.01, 0.03]	1.12	[0.89, 1.43]
Overall Accuracy Parity	0.87	0.88	-0.01	[-0.05, 0.03]	0.99	[0.94, 1.04]
Treatment Equality	1.03	3.24	-2.21	[-4.35, -0.07]	0.32	[0.15, 0.68]

From the outputted fairness metrics we note:

• Independence is likely violated, as evidenced by the statistical parity metric which shows a 9% difference (95% CI: [5%, 13%]) or a ratio of 2.12 (95% CI: [1.49, 3.04]) between females and males. The measures in the independence category indicate that the model predicts a significantly higher mortality rate for females, even after conditioning on age.

• With respect to separation, we observe that all metrics show significant disparities. For instance, equal opportunity shows a -24% difference (95% CI: [-39%, -9%]) in false negative rate (FNR) between females and males. This indicates the model is less likely to detect males at risk of mortality compared to females.

• On the other hand, the sufficiency criterion is satisfied as predictive parity shows no significant difference between males and females (difference: -4%, 95% CI: [-21%, 13%]; ratio: 0.94, 95% CI: [0.72, 1.23]). This suggests that given the same prediction, the actual mortality rates are similar for both males and females.

• Among the additional metrics that assess calibration and discrimination, Brier Score Parity and Overall Accuracy Equality do not show significant disparities. However, Treatment Equality shows a statistically significant difference (difference: –2.21, 95% CI: [–4.35, –0.07]; ratio: 0.32, 95% CI: [0.15, 0.68]), indicating that males have a substantially higher false negative to false positive ratio compared to females. This suggests that male patients are more likely to be missed by the model relative to being incorrectly flagged.

Appendix A: Confidence Interval Construction

The function get_fairness_metrics() computes Wald-type confidence intervals for both group-specific and disparity metrics using nonparametric bootstrap. To illustrate the construction of confidence intervals (CIs), we use the following example involving the false positive rate ($FPR$).

Let $\widehat{\textrm{FPR}}_a$ and $\textrm{FPR}_a$ denote the estimated and true FPR in group $A = a$. Then the difference $\widehat{\Delta}_{\textrm{FPR}} = \widehat{\textrm{FPR}}_{a_1} - \widehat{\textrm{FPR}}_{a_0}$ satisfies (e.g., Gronsbell et al., 2018):

$$\sqrt{n}(\widehat{\Delta}_{\textrm{FPR}} - \Delta_{\textrm{FPR}}) \overset{d}{\to} \mathcal{N}(0, \sigma^2)$$

We estimate the standard error of $\widehat{\Delta}_{\textrm{FPR}}$ using bootstrap resampling within groups, and form a Wald-style confidence interval:

$$\widehat{\Delta}_{\textrm{FPR}} \pm z_{1-\alpha/2} \cdot \widehat{\textrm{se}}(\widehat{\Delta}_{\textrm{FPR}})$$

For ratios, such as $\widehat{\rho}_{\textrm{FPR}} = \widehat{\textrm{FPR}}_{a_1} / \widehat{\textrm{FPR}}_{a_0}$, we apply a log transformation and use the delta method:

$$\log(\widehat{\rho}_{\textrm{FPR}}) \pm z_{1-\alpha/2} \cdot \widehat{\textrm{se}}\left[\log(\widehat{\rho}_{\textrm{FPR}})\right]$$

Exponentiation of the bounds yields a confidence interval for the ratio on the original scale:

$$\left[ \exp\left\{\log(\widehat{\rho}_{\textrm{FPR}}) - z_{1-\alpha/2} \cdot \widehat{\textrm{se}}\left[\log(\widehat{\rho}_{\textrm{FPR}})\right]\right\},\ \exp\left\{\log(\widehat{\rho}_{\textrm{FPR}}) + z_{1-\alpha/2} \cdot \widehat{\textrm{se}}\left[\log(\widehat{\rho}_{\textrm{FPR}})\right]\right\} \right].$$

Appendix B: Practical Fairness Considerations

In the above example, both separation and sufficiency-based fairness criteria are important:

• Separation ensures that patients at true risk are identified across groups, reducing under-detection in specific sub-populations.
• Sufficiency ensures interventions are based solely on predicted need, not protected attributes.

However, 28-day mortality differs by sex (19% for females vs. 14% for males), making it impossible to satisfy multiple fairness criteria simultaneously.

Given this, enforcing independence is likely not advisable in this case, as it could blind the model to true mortality differences. However, the model violates separation, potentially leading to higher false negative rates among male patients and delayed interventions.

See Hort et al. (2022) for strategies to reduce disparities in separation-based metrics.
